| EPS & Glass Wool Panel |
|
|
| |
| Advantages of PUR Sandwich Panel |
|
- Thermal Insulation
- Fireproofing
(Mineral wool/Glass wool)
- Water & Moisture-Proofing
- Sound insulation
- Rigidity
- Easy
Application
- Saving Cost
- Various
Architectural Styles
- Beautiful
Appearance
|
| |
| Technical Data |
|
Raw material
|
color coated steel coil |
| Coil weight |
Max. 5 ton |
| Coil width |
1,040 ~ 1,219mm |
| Coil thickness |
0.45 ~ 0.5mm |
| Panel length |
3~18mm |
| Panel width |
Max.1,000mm |
| Panel thickness |
50~100mm |
| 5ton crane in factory |
| Factory size |
90m(L) X 15m(W) X 6m(H) |
Density
|
- EPS : 10 ~ 21 kg/m3
- Glass wool :
48 ~ 64 kg/m3
- Mineral wool : 100 ~ 120 kg/m3 |
| Inner height of building |
6m |
| Temperature of factory |
18+- 2°C |
|
| |
| Yearly Production Capacity |
|
| EPS Panel |
|
| 50mm Thicknes base |
| 1 minute production |
8-10m in length 10m of laminating |
| 1 hour production |
480m |
| 1 day production |
3.840m |
| 1 year (300 days) production |
1,152,000m |
| efficiency 80% |
900,000m |
|
| |
Yearly Production capacity 900,000m
(8hours working/day) |
| |
| Mineral Wool Panel |
|
| 50mm Thicknes base |
| 1 minute production |
6-8m in length 10m of laminating |
| 1 hour production |
360m |
| 1 day production |
2,880m |
| 1 year (300 days) production |
864,000m |
| efficiency 80% |
700,000m |
|
| |
Yearly Production capacity 700,000m
(8hours working/day) |
| |
| You Can Make Following Panels |
|
|
| |
