| Refrigerator |
|
 |
| |
| Face Down UT-12 |
|
|
| |
| Cycle Time |
12~20 sec |
| Number of working station |
4~7 station |
| Number of station |
24~30 |
| Traveling method |
Shuttle, Track race type |
| Pitch |
1,800~2,300 |
| Manipulator |
1~4 head |
| Model change method |
-manual
-semi auto
-auto : real change with in cycle time |
|
| |
| Face Up UT-12 |
|
|
| |
| Cycle Time |
14~24 sec |
| Number of working station |
4~7 station |
| Number of station |
22~30 |
| Traveling method |
-Shuttle by servo motor
-driver Track race type |
| Pitch |
1,800~2,300 |
| Manipulator |
1 head |
| Model change method |
-manual
-semi auto
-auto : real change with in cycle time |
|
| |
| Stationary Type |
|
|
| |
| Cycle Time |
20~60 sec |
| Number of working station |
8~24 station |
| Number of station |
24~30 |
| Traveling method |
-Up/Down motor
driver
-Conveyor transfer type |
| Pitch |
1,800~2,500 |
| Manipulator |
1 head |
| Injection type |
Face up type |
| Model change method |
-manual
-semi auto
-auto : real change with in cycle time |
|
| |
| Stationary Roto Type |
|
|
| |
| Cycle Time |
24 sec |
| Number of working station |
8 station |
| Number of station |
5 |
| Traveling method |
-Up/Down motor
driver
-Shuttle type moving |
| Pitch |
2,300 |
| Manipulator |
1 head |
| Injection type |
Face up
type |
|
| |
| Stationary Type |
|
|
| |
| Cycle Time |
20~60 sec |
| Number of working station |
7~12 station |
| Number of station |
24~30 |
| Traveling method |
-Up/Down motor
driver
-Conveyor transfer type |
| Pitch |
1,800~2,500 |
| Manipulator |
1 head |
| Injection type |
Face up type |
| Model change method |
-manual
-semi auto
-auto : real change with in cycle time |
|
| |
| Face Up UT-HydC |
|
|
| |
| Cycle Time |
18 sec |
| Number of working station |
14 station |
| Traveling method |
-Up/Down motor
driver
-Shuttle type moving |
| Pitch |
2,300 |
| Manipulator |
1M/C 2 head |
| Injection type |
Face up
type |
|
| |
| Auto Shuttle |
|
|
| |
| Cycle Time |
12~24 sec |
| Number of working station |
Variable |
| Number of station |
20~30 |
| Traveling method |
Servo Motor Driver |
| Inner dimension of mold
carrier |
-length : 1,800 ~ 2,500mm
-width : 1,200mm (Max)
-height : 300mm
(Max) |
| Pitch |
Variable |
| Manipulator |
1 head or 2 head |
| Model change method |
-manual
-semi auto
-auto : real change with in cycle time |
|
| |
| Drum Type |
|
|
| |
| Cycle Time |
45~116 sec |
| Number of working station |
1 |
| Number of station |
4~8 |
| Traveling method |
Servo Motor or hydraulic |
| Inner dimension of mold
carrier |
-length : 2,500mm (Max)
-width : 1,200mm (Max)
-height : 300mm
(Max) |
| Manipulator |
1 head or 2 head |
| Model change method |
-manual
-semi auto
-auto : real change with in cycle time |
|
| |
| Auto-Quick Paternoster |
|
|
| |
| Cycle Time |
11~24 sec |
| Number of working station |
4~6 station |
| Number of station |
18~30 |
| Traveling method |
Servo Motor Driver |
| Inner dimension of mold
carrier |
-length : 1,800 ~ 2,500
mm
-width : 1,200 mm (Max)
-height : Auto
Model Change Type 250mm
Manual type 300mm |
| Pitch |
max 1,800 |
| Manipulator |
1 head or 2 head |
| Model change method |
-manual
-semi auto
-auto : real change with in cycle time |
|
| |
